Javad TRIUMPH-1 Operator's Manual page 42

Description and Operation
Configuration
Configuring the Receiver
4. Open the Log files tab and then TriPad tab and set the following parameters (Table 7), click Apply
(Figure 27 on page 43).
Parameter
Implicit Message
Output Period
Elevation mask angle
File name prefix
FN key mode
Initial dynamic mode
42
Figure 26. General tab
Base
15 seconds
15 degrees
Enter a unique ID, such as the last 3 digits of receiver's serial number. By deafault the
prefix is log
(starts/stops the data recording when FN button is used)
Select LED blink mode switch for Static data
-
Table 7. TriPad Settings
Select Occupation mode switch (for RTK)
Select Dynamic (for trajectory survey)
Rover
