TMS700E SERVICE MANUAL
• Carwell treatment is available in 16 ounce spray bottles
from Manitowoc Crane Care (order part number
8898904099).
• After application of the treatment is complete, wash or
clean film residue from lights, windshield, grab handles,
ladders/steps and all access areas to crane, as
necessary.
Please contact Manitowoc Crane Care should you have any
questions.

Areas of Application

Refer to Figure 9-4
• The underside of the unit will have full coverage of the
rust inhibitor. These are the only areas that a full coat of
the rust inhibitor is acceptable on the painted surfaces.
Grove
Areas include; Valves, hose ends and fittings, Swivel,
pumps, axles, drivelines, transmission, slew ring
fasteners and all interior surfaces of the frame.
• Frame application areas are; hose ends and fittings, all
unpainted fasteners and hardware, all bare metal
surfaces, outrigger pads, and back up alarm hardware.
• Superstructure applications are; hose ends and fittings,
wire rope on hoist roller, tensioning springs on hoists, all
unpainted fasteners and hardware, valves, slew ring
fasteners and all bare metal surfaces.
• Boom applications areas are; pivot pins, hose ends and
fittings, jib pins and shafts, all bare metal surfaces,
headache ball pins/ hook block pins and fasteners.
• All hardware, clips, pins, hose connections not painted
will have treatment applied.
Published 01-29-2015, Control # 512-01
LUBRICATION
9
9-17
