BOOM
Item
1
Section 4
2
Section 3
3
Section 2
4
Section 1
5
Upper Telescope Cylinder
6
Lower Telescope Cylinder
7
Sheave Mounting Assembly
8
Upper Cylinder Support Foot
9
Wear Pad
10
Sheave Assembly
11
Sheave Shaft
12
Sheave Shaft Plate
13
Cable Retainer
14
Extend Cables
15
Retract Cables
16
Skid Pad
17
Lower Cylinder Mount
18
Shaft
19
Upper Cylinder Support
20
Wear Pad Support
21
Wear Pad
22
Cable Roller
23
RCL Cable Mounting Angle
24
Upper Wear Pad Keeper Plate
25
Lower and SIde Wear Pad Keeper Plate
26
Upper Boom Nose Sheaves
27
Lower Boom Nose Sheaves
28
Cable Retainer Pin
29
Sheave Shaft/Swingaway Anchor Lugs
30
Guide Block
31
Shim
4-4
Description
Published 01-29-2015, Control # 512-01
TMS700E SERVICE MANUAL
Shut down the crane and disconnect the batteries before
proceeding.
12. Take up the slack on the boom lifting device.
13. Remove the bolt, lockwasher, nut, and retaining pin
securing the boom pivot shaft. Remove the grease
fittings from the pivot shaft. Remove the boom pivot
shaft.
14. Raise the boom clear of the crane and lower to ground
level for service.

Disassembly

1.
Remove the boom in accordance with the Removal,
page 4-2 procedures outlined in this section.
2.
If necessary, on the left side of the boom remove the two
bolts and washers securing the RCL cable angle
brackets to the base, Section 2, and Section 3.
3.
On the top front of Section 1, remove the cotter pins, four
spacers, shaft, and eight cable rollers.
4.
Repeat step 3 on Section 2, removing seven rollers.
5.
Repeat step 3 on Section 3, removing six rollers.
6.
On the left side of Section 1, remove the bolt, two nuts,
and the trigger weldment from the brackets.
7.
Remove the clamp halves securing the two hydraulic
lines to the rear of Section 1. Tag and disconnect the two
hydraulic lines from the lower telescope cylinder. Cap or
plug all openings.
8.
Remove the five bolts and hardened washers securing
each lower telescope cylinder rod mounting plate to the
rear of Section 1.
NOTE:
The combined weight of the boom Section 2,
Section 3, and Section 4, including the telescope
cylinders, is approximately 9939 kg (20,911 lb).
9.
Slide the assembly out of the base part way.
WARNING
