ELECTRIC SYSTEM
Table 3-15
Component
Windshield
Wiper Motor
F18, wiper/washer switch, motors in
and Windshield
parallel, grounds
Washer Pump
Motor
Heater or A/C
F16, FAN switch, fan motor, ground
Fan
Cab Circulating
F13, switch, motor, ground
Fan
F16 to FAN switch to A/C ON-OFF
switch to fans relay coil to ground.
Parallel circuit to LED indicator in A/C
A/C Control
ON-OFF switch to ground. Parallel
Functions
circuit to thermostat contacts to
binary pressure switch contacts to A/
C compressor clutch to ground
Fuse F17 to fans relay contacts to
A/C Condensor
condensor fan motors in parallel to
Fan Motors
ground
F14, crane function switch, seat
switch, left armrest switch, crane
function relay (K5) coil, ground.
Branch in parallel from crane function
Crane Function
switch to crane function relay
contacts to crane function solenoid
valve to ground. Parallel circuit to
LED indicator in switch to ground
Main and F15, branch for each hoist (driver
Auxiliary Hoist assembly, sensor, driver assembly,
Rotation ground). Parallel branch through
Indicators thumper to driver assembly
F11, RCL CPU and RCL crane
RCL
components, grounds
Lockout F11, RCL CPU, three or four lockout
Function solenoid valves in parallel, grounds
F10, swing brake release switch,
Swing Brake
swing brake release solenoid valve,
Release
ground. Parallel circuit to LED
Function
indicator in switch to ground
From upstream of crane function
relay contact (see crane function
Hydraulic Boost circuit) to hydraulic boost switch to
Function hydraulic boost solenoid to ground.
Parallel circuit to LED indicator in
switch to ground
F12 to main hoist high speed switch
Main Hoist High to hoist speed solenoid valve on hoist
Speed Function to ground. Parallel circuit to LED
indicator in switch to ground
3-14
Circuit
Published 01-29-2015, Control # 512-01
TMS700E SERVICE MANUAL
Component
For hoist up, F11 to RCL CPU to aux
hoist switch to auxiliary hoist up
solenoid valve to ground. For hoist
Auxiliary Hoist
down, CB12 to aux hoist switch to
On/Off function
auxiliary hoist down solenoid valve to
ground. Parallel circuit to LED
indicator in switch to ground
Skylight Wiper F13, wiper switch (on motor), motor,
Motor grounds
Beacon Light F18 to beacon light to ground
Switch LED's F18 to seven parallel LED's to ground
3. Repair is straightforward.
a. MOTOR: check and/or replace fuse, remove faulty
motor or faulty trigger (switch, relay), install new
motor or trigger, test motor. For further information,
see the applicable section in this manual.
b. SOLENOID VALVE: check and/or replace fuse,
remove faulty valve or solenoid, install new valve or
solenoid, fill fluid system, test valve.
c. RCL: check and/or replace fuse, repair per RCL
manual, test per RCL manual.
d. ROTATION INDICATOR: check and/or replace fuse,
remove driver assembly or sensor, install driver
assembly or sensor, test thumper. For further
information on rotation indicator, see Hoist Drum
Indicator System, page 5-10 or the applicable SM
package.

Alternator Replacement

NOTE: On cranes with air conditioning it may be
necessary to move the compressor to gain access
to the alternator.
Removal
CAUTION
To prevent damage to electronics, in order: Ensure
keyswitch has been off 2 minutes, Battery disconnect is in
the off position, Remove ECM power fuse, Remove
negative cables, Remove positive cables (if required).
1. Turn the ignition switch off two minutes before
proceeding to the next step.
2. Turn the battery disconnect switch to OFF.
3. Remove the ECM power fuse.
4. Disconnect the batteries starting with the negative
terminals.
5. Open the engine compartment.
Circuit
