TMS700E SERVICE MANUAL
Item Description
25 Swingaway Base
26 Swingaway Stinger
27 Shock Wear Pad and Shim
28 Ramp Wear Pad and Shim
DETAIL C
Item Description
29 Swingaway Base
30 Swingaway Stinger
31 Stinger Attach Pin and Hitch Pin
32 Adjusting Bolts
33 Pin Stowage Lug
34 Upper Support
35 Lower Mount
36 Wear pad
37 Pin Mount
38 Upper Hanger
39 Lower Hanger
DETAIL D
Grove
29
Published 01-29-2015, Control # 512-01
27
28
30
37
36
35
FIGURE 4-5 continued
BOOM
25
26
32
38
34
39
31
32
33
4-27
4
