List Of Specifications

General

Model . . . . . . . . . . . . . . . . . . . .TMS700E13 Series
Rated Capacity . . . . . . . . . . See Load Chart in cab
Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 x 4 x 4
Gross Weight . . . . . . . . . . . . 43,956 kg (96,906 lb)

Dimensions

NOTE: Dimensions listed are for a crane with all
components fully retracted in the travel mode.
Wheelbase . . . . . . . . . . . . . . . . . 5639 mm (222 in)
Overall Crane Length . . . . . . . .13,538 mm (533 in)
Overall Crane Width . . . . . . . . . . 2591 mm (102 in)
Overall Crane Height . . . . . . . . . 3586 mm (141 in)
Tail-Swing . . . . . . . . . . . . . . . . . . 4102 mm (162 in)
Outrigger Spread
Retracted . . . . . . . . . . . . . . . . 2429 mm (96 in)
Mid Extend . . . . . . . . . . . . . . 4262 mm (168 in)
Fully Extended . . . . . . . . . . . 6096 mm (240 in)

Capacities

Fuel Tank . . . . . . . . . . . . . . . . . . . . . .367 l (97 gal)
Coolant System. . . . . . . . . . . . . . . . . . . See Engine
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . Specifications
Engine Lubrication System . . . . . . . . . . See Engine
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . Specifications
Hydraulic Tank (Reservoir Capacity)
Total . . . . . . . . . . . . . . . . . . . . . .564 l (149 gal)
at Full Level . . . . . . . . . . . . . . . .507 l (134 gal)
at Add Level . . . . . . . . . . . . . . . .477 l (126 gal)
Expansion Space . . . . . . . . . . . . . .57 l (15 gal)
Hoists . . . . . . . . . . . . . . . . . . . . . . . .14.7 l (15.5 qt)
Swing Gearbox . . . . . . . . . . . . . . . . .1.30 l (2.75 pt)
Front Axle Hubs . . . . . . . . . . . . . . . . . . 0.95 l (1 qt)
Front Rear Axle Differentials . . . . . . . . . .27 l (57 pt)
Rear Rear Axle Differentials . . . . . . . . 17.5 l (37 pt)
Transmission. . . . . . . . . . . . . . . . . . . . . .19 l (20 qt)
Pump Drive . . . . . . . . . . . . . . . . . . . . . .2.4 l (2.5 qt)

Transmission

Speeds . . . . . . . . . . . . . . . . . 11 forward - 3 reverse
Gear Ratios
LL2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11.85
Low . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16.30
LL1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26.08
Low
First . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7.41
Second. . . . . . . . . . . . . . . . . . . . . . . . . . . .5.23
Third. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3.79
Fourth. . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.77
High. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fifth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.95
Sixth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.38
Seventh . . . . . . . . . . . . . . . . . . . . . . . . . . .1.00
Eighth. . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.73
Reverse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13.03
High . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3.43
1-2

Clutch

Type . . . . . . . . . . . . . . . . . 2 plate pull type dry disc

Engine

Cummins ISX12-2013 or QSMT3 inline 6 cyl.
Turbo-Charged
Displacement . . . . . . . . . . . . 11.9 l (729 cu in)(ISX)
. . . . . . . . . . . . . . . . . . . . . .10.9 l (665 cu in)(QSM)
Firing Order. . . . . . . . . . . . . . . . . . . . . . 1-5-3-6-2-4
Lube Amount . . . . . . . . . . . . . . 41.6 l (11 gal)(ISX)
. . . . . . . . . . . . . . . . . . . . . . . . . . 34 l (36 qt)(QSM)
Coolant System . . . . . . . . . . . . . . . . . . . 54 l (57 qt)

Axles

Front
Type . . . . . . . . . . . . . . . . . . . . . . . . Non-drive steer
Rear
Type . . . . . . . . . . . . . . . . . Single reduction tandem
Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.38:1

Brakes

Type . . . . . . . . . . . . . . . . . . . . Air operated S-Cam
Size. . . . . . . . . . . . . . 419 x 178 mm (16.5 x 7.0 in)

Wheel and Tires

Lugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Torque. . . . . . . . . . 610 to 678 Nm (450 to 500 lb-ft)
Tire Size
For roading and lifting pressures, refer to the Tire
Inflation Decal.

Swing Gearbox

Reduction Ratio . . . . . . . . . . . . . . . . . . . . . . . . 36:2
Output Torque . . . . . . . . . . . 5.54 Nm (49,825 lb-in)

Boom

Length. . . . . . . . . . . . 10.84 to 33.5 m (35 to 110 ft)
Power . . . . . . . . . . . . . . . . . . 4 Section, Full Power
Elevation . . . . . . . . . . . . . . . . . . . -3 to +78 degrees
Extensions
*Extensions
degrees

Swivel Assembly

Electrical . . . . . . . . . . . . . . . . . . . . . . . 49 Slip Rings
Hydraulic. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 ports
Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 ports

Hydraulic Pumps

NOTE:
Published 01-29-2015, Control # 512-01
TMS700E SERVICE MANUAL
Front . . . . . . . . . . . . . . . . . . . . . . 445/65R22.5
Rear. . . . . . . . . . . . . . . . . . . . . . . 315/80R22.5
Fixed* . . . . . . . . . . . . . . . . . . . . .9.75 m (32 ft)
Folding* . . . . . . . . 9.75 or 17.07 m (32 or 56 ft)
Lattice Extension . . . . . . . . . . . . . . . . . . . . . 20
and 6.1 and 12.2 m (40 ft)
are offsettable
Pump output figures are theoretical.
at 0 or 45
