LUBRICATION
Item
1 Engine Crankcase
2 Engine Cooling System
3 Transmission
4 Pump Drive
5 Pump Drive Shaft U-Joints and Spline
6 Clutch Throw Out Bearing
7 Clutch Linkage
8 Transmission Shift U-Joints and Control Unit
9 Power Steering Gearbox
10 Steering Relay Arms
11 Front Aluminum Wheel Pilots
12 Front Axle Hubs
13 Front Axle Tie Rod Ends
14 Front Axle King Pins
15 Front Axle Brake Slack Adjusters
16 Front Axle Brake Camshafts
17 Rear Aluminum Wheel Pilot
18 Front Rear Axle Differential
19 Rear Rear Axle Differential
20 Rear Axle Brake Slack Adjusters
21 Rear Axle Brake Camshafts
22 Outrigger Beams
23 Jack Cylinder Support Tubes
24 Jack Cylinder Barrels
25 Hydraulic Reservoir
26 Hydraulic Filter
27 Fuel Filter
28 Air Cleaner
29 Coolant Strainer (Superstructure Cab Heater)
30 Fuel Filter
CAUTION
Axle fluid levels shall be adjusted to bottom of fill plug
threads. Check with crane on level ground, at its normal
ride height; cold or room temperature oil only.
9-8
Description
Published 01-29-2015, Control # 512-01
TMS700E SERVICE MANUAL
15. Rear Aluminum Wheel Pilots
Lube Type - ASC
Lube Interval - When wheels are removed for service.
Lube Amount - Generously coat the wheel pilot or hub
pads with antiseize compound. Do not apply antiseize
compound to the face of the wheel of the hub.
Application - Brush on. 8 places
16. Front Axle Brake Slack Adjusters
Lube Type - EP-MPG
Lube Interval - 1000 hours
Lube Amount - Until grease extrudes
Application - 4 grease fittings
17. Front Axle Brake Camshafts
Lube Type - EP-MPG
Lube Interval - 1000 hours
Lube Amount - Until grease extrudes
Application - 4 grease fittings
18. Front Rear Axle Differential
Lube Type - SSGL-5
Lube Interval - Check lubricant level every 250 hours
and refill as necessary. Drain, fill, change filter, and
clean magnetic drain plug every 80,000 km (50,000 mi)
or 2 years, whichever interval occurs first.
CAUTION
Use of non-semi-synthetic lubricant may damage
components and/or invalidate published lubrication
intervals.
Axle fluid levels shall be adjusted to bottom of fill plug
threads. Check with crane on level ground, at its normal
ride height, cold or room temperature oil only. A 30 minute
drain-down time is required before checking fluid level if
crane has been recently moved.
If the makeup amount is substantially more than 0.23 l
(0.5 pt) check for leaks.
Lube Amount - Capacity - 27 l (57 pt) Normal makeup -
less than 0.23 l (0.5 pt).
Application - Fill to bottom of fill plug threads
NOTE: Lube level (Figure 9-2) close enough to the hole to
be seen or touched is not sufficient. It must be level
with the hole.
When checking lube level, also check and clean
housing breathers.
