ELECTRIC SYSTEM
NOTE: Refer to (Figure 3-2, 3-3, and 3-4), and Table 3-
3 and 3-4 for fuse and relay identification.
2
3-6
1
6871-2
Item Description
1 Fuse Installation
2 Fuse and Relay Panel
3 Harness Connector
4 Harness Connector
5 RCL Cable
Published 01-29-2015, Control # 512-01
TMS700E SERVICE MANUAL
3
4
Partial Rear View Of Cab
5
6871-1
FIGURE 3-3
