TMS700E SERVICE MANUAL
4
3
Item Description
1 Breather Plug
2 Filler Plug
3 Swing Drive and Brake
4 Hydraulic Apply Brake Port
5 Hydraulic Release Brake Port
Grove
7
1
8
Published 01-29-2015, Control # 512-01
2
1
6470-1
Item Description
6 Level Plug
7 Motor
8 Pinion
9 Drain Plug
SWING SYSTEM
5
6
9
FIGURE 6-1
6-3
