TMS700E SERVICE MANUAL
• Multiplier bar handles must be propped or supported
within the outer 1/4 of the handle length, or serious
under or over tightening will occur.
To convert pounds-foot (lb-ft) of torque to newton meters
(Nm), multiply the pounds-foot quantity by 1.3558.
To convert pounds-inch (lb-in) of torque to newton meters
(Nm), multiply the pounds-inch quantity by 0.11298.
SAE Grade 1
and Grade 2
HHCS
Table 1-3: UNC (Course) Thread: Torque Values for Zinc-Flake Coated and Untreated Fasteners
SAE Grade
5
Zinc-Flake
8
5
Untreated
8
NOTE: Studs shall be torqued using capscrew values when grade is known.
Grove
SAE Grade 5
HHCS
Socket Head
Capscrew
Bolt Diameter - Inches
Torque Values (Pounds-Foot, Maximum/Minimum)
1/4 5/16 3/8 7/16
7 14 25 40
10 20 36 57
9.0 19 32 52
7.7 17 30 48
12.5 26 48 73
11.5 24 44 67
Published 01-29-2015, Control # 512-01
Torque Values
The following tables list the torque values for both ASME
standard and metric fasteners. The tables list the values for
grade 5 and grade 8 zinc-flake coated, untreated (black)
finish and stainless steel fasteners.
SAE Grade 7
HHCS
Socket Head
Serrated
Shoulder
Flange Head
Screw
1/2 9/16 5/8 3/4
61 88 121 213
86 124 171 301
78 114 156 270
72 106 144 249
120 161 234 385
110 143 216 355
INTRODUCTION
SAE Grade 8
HHCS
FIGURE 1-3
7/8 1 1-1/8 1-1/4
342 512 636 884
483 723 1032 1433
416 606 813 1141
384 560 751 1053
615 929 1342 2043
567 857 1234 1885
1
1-1/2
1532
2488
2028
1865
3276
3024
1-13
