POWER TRAIN
7
6781-1
Item
Fuel Return Line - From Fuel Cooler (QSM
1
shown)
2
Fuel Supply Line - To Engine
3
Fuel Filter-Water Separator
4
Fuel Level Senders
7-10
3
2
Description
Published 01-29-2015, Control # 512-01
5
1
8
Item
5
Vent Tube
6
Mounting Strap
7
Fuel Tank
8
Plug
TMS700E SERVICE MANUAL
4
6
FIGURE 7-4
Description
