TMS700E SERVICE MANUAL
off, then either the CPU is damaged or the sensor is
damaged. The following should be used only after using the
diagnostic LEDs.
1
CONTROL MODULE - CPU
Item Description
1 Control Module - CPU
2 Bracket
3 CPU Bolt (not shown) and Washer
Sensor (horizontal under brake clutch,
4 through support end bracket, shown with
lock nuts)
5 DTM3S
Grove
4
8
9
10
Published 01-29-2015, Control # 512-01
HOIST AND COUNTERWEIGHT
Sensing End
3
2
To Sensor
6
Connects to DT3S
11
SINGLE AXIS CONTROLLER
Item
6 DTM3P
7 DT3P
8 Green LED
9 Amber LED
10 Red LED
11 Lever Handle
Support End Bracket
Lock Nuts
31 mm (1.21 in.)
1
5
7
12
13
FIGURE 5-5
Description
5
5-11
