POWER TRAIN
4
FIGURE 7-12
Item
1 Clutch Assembly
2 Clutch Pedal Adjusting Lever
3 Governor Spring
4 Pilot Bearing (ref.)
5 Crank
7-32
2
Description
Published 01-29-2015, Control # 512-01
1
9
8
2
5
3
10
1
6, 7
8
5
3
10
4749
Item
6 Lockwasher
7 Bolt
8 Clutch Release Shaft and Yoke
9 Throw Out Bearing
10 Throw-Out Bearing Grease Fitting
