LUBRICATION
Table 9-1: Standard Lube Symbol Chart
Symbol
AFC Antifreeze/Coolant - 50/50 Blended, Fully Formulated - SAE Grade J1941
EO Engine Oil - SAE 15W-40, API Service Classification CJ-4. (CI-4 for pre-2007 ISM engines)
EP-MPG Extreme Pressure Multipurpose Grease - Lithium Soap Base, NLGI Grade 2.
SGL-5 Synthetic Gear Lubricant - SAE Grade 50, API Gravity 23.
HYDO Hydraulic Oil - Must meet John Deere Standard JDM-J20C, Allison C4, and ISO 4406 level.
SSGL-5 Semi-Synthetic Gear Lubricant - SAE Grade 80W-90, API Service Designation GL-5.
ASC Anti-Seize Compound - Military Specifications MIL-A-907E.
EP-OGL Open Gear Lubricant - LPS Dry Force 842 Moly Lube
EPGL-5H Extreme Pressure Gear Lubricant - SAE Grade 80W-140
LCC Liquid Coolant Conditioner
DEF Diesel Exhaust Fluid
SCA Supplemental Coolant Additive
Table 9-2
Lube Description
50/50 Fully Formulated Anti-Freeze Coolant
Engine Oil SAE 15W40, CJ4
Engine Oil SAE 15W40, CI4
Extreme Pressure Multi-Purpose Grease
Synthetic Gear Lube
Hydraulic Oil
Semi-Synthetic Gear Lube
Anti-Seize Compound
Open Gear Lube
EPGL Gear Lube
Liquid Coolant Conditioner
Diesel Exhaust Fluid
Wire Rope
The following describe the lubrication points and gives the
lube type, lube interval, lube amount, and application of
each. Each lubrication point is numbered, and this number
corresponds to the index number shown on the Lubrication
Chart (refer to Figure 9-1 through 9-3, Table 9-1 and Table 9-
2).
9-4
Lubrication Description
Published 01-29-2015, Control # 512-01
TMS700E SERVICE MANUAL
Description
Lube Specification
6829101130
6829104182
6829003483
6829003477
6829013433
6829006444
6829012964
6829003689
6829104478
6829006240
6829012858
80019225
See Service Manual
CAUTION
The following lube intervals are to be used as a guideline
only. Actual lube intervals should be formulated by the
operator to correspond according to conditions such as
continuous duty cycles and/or hazardous environments.
