Manitowoc Grove TMS700E Service And Maintenance Manual page 326

UNDERCARRIAGE
Item
1 Jack Cylinder
2 Cotter Pins
3 Cylinder Retaining Pin
4 Cylinder Head Wear Ring
5 Piston Wear Ring
6 Jack Pad (Float Pad)
7 Bushing
8 Hex Nut
9 Lockwasher
10 Tilt Plate
8-74
2
3
13
1
15
16
7
14
Description
Published 01-29-2015, Control # 512-01
19
20
18
Welded tube shown with cylinder inside
17
and with cylinder tube cap outside
fastened to cap bracket inside. Wear
4
rings are shown inside because they
keep cylinder and tube from making
metal-to-metal contact. Cylinder rod end
is on top and barrel end is on bottom.
5
1
6
Item
11 Capscrew
12 Flatwasher
13 Plug
14 Capscrew
15 Locknut
16 Flatwasher
17 Cylinder Tube Cap
18 Washer
19 Acorn Nut
20 Cap Bracket
TMS700E SERVICE MANUAL
11
12
9
8
10
6512
Description
FIGURE 8-71
