TMS700E SERVICE MANUAL
Telescope Pedal Control Valve Functional
Check (with Auxiliary Hoist Option)
1. Start the engine and run it at normal speed.
2. Telescope the boom the whole way out and then the
whole way back in. Verify proper telescoping.
NOTE: R.H. and L.H. controllers oriented from seated operator.
Ports of control lever seen facing aft looking at seat with armrest in up position.
Swing
FWD
1
FWD
7
Grove
Telescope or
Aux Hoist
FWD
BACK
2
5
Main Hoist
Lift
FWD
BACK
9
8
Published 01-29-2015, Control # 512-01
3. Check valve and lines for leakage. Make repairs as
needed.
BACK
4
3
6
5, 9
BACK
6, 10
4
4
3
6461-3
10
HYDRAULIC SYSTEM
1, 7
3
2, 8
FIGURE 2-23
2-35
