INTRODUCTION
Table 1-1 Axle Weight Distribution Table
Description
Maximum Tire & Wheel Loads Allowed
Maximum Axle Loads Allowed
Standard Carrier Assy (8x4x4)
Superstructure Assy with main and aux
hoists, w/cables
Boom Assy w/pivot pins, 2 over 3
sheaves, RCL
Lift Cylinder and lower shafts
Complete Basic Machine: Carrier Ass'y,
S/S Ass'y, 4-Section Boom, Cummins
ISX 11.9 2010 Engine, 445/65R22.5
Goodyear Front Tires, 315/80R22.5
Goodyear Rear Tires, Full Fuel and
Hydraulic Oil, cable on both hoists
10 - 17 m (33 - 56 ft) Bi-fold Boom
Extension
Boom Extension Carrier Brackets
Aux Boom Nose
6.1 m (20') Boom Extension Insert w/RCL
(pinned at boom nose)
5500 lb counterweight on superstructure
- master
5500 lb counterweight on superstructure
- slab
5500 lb counterweight on superstructure
- slab
5500 lb counterweight stowed on deck -
master
5500 lb counterweight stowed on deck -
slab
5500 lb counterweight stowed on deck -
slab
7.5 t (8.3 ton) Headache Ball (Swivel) - in
stowage tray
7.5 t (8.3 ton) Headache Ball (Swivel) -
tied to front bumper
36 t (40 ton) Hookblock (3 sheave) - tied
to front bumper
45 t (50 ton) Hookblock (3 sheave) - tied
to front bumper
55 t (60 ton) Hookblock (5 sheave) - tied
to front bumper
Rigging
1-6
CG To CL
Weight
Rear Bogie
kg (lb)
cm (in)
304.60(119.92) 18919(41708)
-51.69(-20.35) 6422(14157)
489.46(192.70) 8241(18169)
210.82(83.00) 791(1743)
280.21(110.32) 34372(75777)
571.30(224.92) 1132(2495)
467.36(184.00) 133(293)
1097.28(432.00)
407(898)
-227.03(-89.38) 2495(5500)
-227.03(-89.38) 2495(5500)
-227.03(-89.38) 2495(5500)
481.03(189.38) 2495(5500)
481.03(189.38) 2495(5500)
481.03(189.38) 2495(5500)
830.58(327.00) 161(355)
942.34(371.00) 161(355)
955.04(376.00) 373(823)
955.04(376.00) 458(1010)
955.04(376.00) 581(1280)
170.18(67.00)
