CVM-E3-MINI
3�4�- CVM-E3-MINI-FLEX: ROGOWSKI SENSORS
The CVM-E3-MINI-FLEX model measures currents using flexible sensors, based on the Rogowski coil
principle.
The flexibility of the sensor allows it to measure an alternating current irrespective of the position of
the conductor.
CIRCUTOR has 1 Rogowski sensor model that can be used with the CVM-E3-MINI-FLEX: FLEX-MAG�
shows the connection of the sensors and
Table 6
Note: For more information, consult the corresponding sensor guide.
Instruction Manual
the maximum position error.
Table 5
Table 5: Position error�
Position
A
B
A
B
Table 6: Probe cable terminal connections
Probe cable terminal connections
FLEX-MAG
Canal de medida / Measuring channel
Black : Shield (SHLD)
Blue: Common (C)
Green: Measuring channel (L1, L2, L3, N)
Error
± 1%
A ± 3%
Shield
Común / Common
