VLT® Midi Drive FC 280
Operating Guide
Parameter Option/range
–
Parameter 42-33
Parameter Set
Name
–
Parameter 42-35
S-CRC Value
–
Parameter 42-36
Level 1 Password
Parameter 42-42 0.1-3600.0 s
Delay Time
Parameter 42-43 0-99%
Delta T
Parameter 42-60
[0] None
Telegram Selec-
[1] PROFIsafe
tion
Std. Tel. 30
1-65534
Parameter 42-61
Destination Ad-
dress
Parameter 42-80 0-0xFFFFFFFF
Safe Option Status
Parameter 42-81 0-0x7FFFFFFF
Safe Option Status
2
0-0xFFFFFFFF
Parameter 42-82
Safe Control Word
0-0xFFFFFFFF
Parameter 42-83
Safe Status Word
98 | Danfoss A/S © 2022.02
Default Usage
The reset sources of [1] Drive Safe Reset are:
• Digital input (Select [100] Safe Option Reset on 1
of the digital inputs for this source type to work).
• The reset signal via a fieldbus. (For the fieldbus
reset to work, set parameter 8-14 Configurable
Control Word CTW to [3] Safe Option Reset.)
SafeSet1 Enter the name of the safety parameter set (8 charac-
ters). Use this parameter to identify the safety config-
urations.
– The CRC value of safe parameter set.
12345678 Password for safe parameter set to prevent unau-
thorized modification.
10.0 s Time until STO is activated.
2% The value subtracts from the time in parameter 42-42
Delay Time to get motor to stop before the timer ex-
pires.
[0] None
Select the safe fieldbus type and the telegram stand-
ard for the safety option.
Selecting [0] None means the safe fieldbus communi-
cation is disabled.
Selecting [1] PROFIsafe Std. Tel. 30 means the PROFI-
safe communication is enabled, and the telegram
standard is PROFIsafe Std. Tel. 30. PROFIsafe Std. Tel.
30. For more information, see
If the fieldbus communication is enabled and the re-
set signal comes via the fieldbus, this parameter also
defines whether the drive is reset or only the safety
option is reset.
1 Enter the safe fieldbus destination address within the
safe network. This address must be unique in the net-
work where PROFIsafe operates. The address should
match the address specified in the PLC software.
0 Show the status word 1 of the safety option as a hex-
adecimal value. Refer to
0 Show the status 2 word of the safety option as a hex-
adecimal value. Refer to
0 Show the safe control word as a hexadecimal value.
0 Show the safe status word as a hexadecimal value.
6.5.1 PROFIsafe.
Table 48.
Table 49.
AQ381425076031en-000101 / 130R1223
Safety Functions
Con- Data
ver- type
sion
index
– Visible
String
– u_int16
– Visible
String
-1 u_int16
0 u_int8
– u_int8
– u_int16
0 u_int32
0 u_int32
– u_int32
– u_int32
