VLT® Midi Drive FC 280
Operating Guide
Message
0 RPM
0.00A
!1(1)
SO Data Confirmation
Press [OK] to confirm
(commissioning test must be
performed) or [CANCEL] to
abort
Status
!1(1)
0 RPM
None
0.00KW
SO Custom. completed
SO RESET required!
!Safe Stop [W68]
Off Remote SO Req.RESET
Status
!1(1)
0 RPM
None
0.00KW
SO Custom. aborted
SO RESET required!
!Safe Stop [W68]
Off Remote SO Req.RESET
6.7.2 Configuring PROFIsafe with Siemens TIA Portal
This section explains how to configure PROFIsafe communication between VLT® Midi DriveFC 280 and Siemens device with Siemens
TIA Portal.
6.7.2.1 Configuring the Hardware
Configure the PROFINET communication with the F-PLC using the VLT® PROFINET MCA 120 Installation Guide.
Procedure
1.
In the Siemens TIA Portal, select Open the project view.
2.
Double-click Devices and Networks.
The Hardware Configuration dialog box opens.
3.
Select the Danfoss device in the network view and drag it into the workspace.
The project view shows the F-PLC and the Danfoss device.
88 | Danfoss A/S © 2022.02
Description
Press [OK] to complete the customization of the safety option. A reset is required to finalize this
procedure.
Press [Cancel] to abort the customization of the safety option. A reset is required to finalize this
procedure.
Safety Functions
AQ381425076031en-000101 / 130R1223
