VLT® Midi Drive FC 280
Operating Guide
Number Description
88 Option detection
95 Broken belt
99 Locked rotor
120 Position control
fault
126 Motor rotating
127 Back EMF too high
188 STO internal fault
nw run Not while running
Err. A wrong password
was entered
These faults may be caused by mains distortions. Installing a Danfoss line filter may rectify this problem.
1
This alarm cannot be reset via parameter 14-20 Reset Mode automatically.
2
8.4.2 Alarm Words, Warning Words, and Extended Status Words
For diagnosis, read out the alarm words, warning words, and extended status words.
Table 59: Description of Alarm Word, Warning Word, and Extended Status Word
Bit Hex Dec
0 00000001 1
1 00000002 2
2 00000004 4
3 00000008 8
4 00000010 16
112 | Danfoss A/S © 2022.02
Warning Alarm Trip
lock
– X X
X X –
– X –
– X –
– X –
X – –
– X –
(2)
– – –
– – –
Alarm word Alarm
word 2
Brake check Reserved
Pwr. card Gate drive
temp voltage
fault
Earth fault Reserved
Ctrl. card Reserved
temp
Reserved
Ctrl. word
TO
Cause
The option is removed successfully.
–
Rotor is blocked.
–
PM motor is rotating when AMA is performed.
The back EMF of PM motor is too high before starting.
24 V DC supply is connected to only 1 of the 2 STO terminals
(37 and 38), or a failure in STO channels is detected. Ensure that
both terminals are powered by a 24 V DC supply, and that the
discrepancy between the signals at the 2 terminals is less than
0.5 s. If the fault still occurs, contact the local Danfoss supplier.
Parameters can only be changed when the motor is stopped.
Occurs when using a wrong password for changing a pass-
word-protected parameter.
Alarm Warning Warning
word 3 word word 2
STO func- Reserved Reserved
tion fault
MM alarm Pwr. card Reserved
temp
Reserved Reserved Reserved
Reserved Ctrl. card Reserved
temp
Reserved Ctrl. word Reserved
TO
Maintenance, Diagnostics, and
Troubleshooting
Extended Extended
status status
word word 2
Ramping Off
AMA tun- Hand/Auto
ing
Start PROFIBUS
CW/CCW OFF1 ac-
tive
Slowdown PROFIBUS
OFF2 ac-
tive
Catchup PROFIBUS
OFF3 ac-
tive
