Drive typical shaft output [kW (hp)]
Maximum cable cross-section (mains and motor)
2
[mm (AWG)]
Estimated power loss at rated maximum load [W]
(1)
Weight enclosure protection rating IP20 [kg (lb)]
Weight enclosure protection rating IP21 [kg (lb)]
Efficiency [%]
(2)
The typical power loss is at nominal load conditions and expected to be within ±15% (tolerance relates to variety in voltage and cable conditions).
1
Values are based on a typical motor efficiency (IE2/IE3 border line). Motors with lower efficiency add to the power loss in the drive, and motors with
high efficiency reduce power loss. Applies to dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power
losses sometimes rise. LCP and typical control card power consumptions are included. Further options and customer load sometimes add up to 30
W to the losses (though typically only 4 W extra for a fully loaded control card or fieldbus). For power loss data according to EN 50598-2, refer to
https://ecosmart.mydrive.danfoss.com/.
Measured using 50 m (164 ft) shielded motor cables at rated load and rated frequency. For energy efficiency class, see chapter Ambient Conditions.
2
For part load losses, see https://ecosmart.mydrive.danfoss.com/.
9.2 Mains Supply
Supply terminals
Supply voltage
Supply voltage
Supply frequency
Maximum imbalance temporary between mains phases
True power factor (λ)
Displacement power factor (cos ϕ)
Switching on input supply (L1/N, L2/L, L3) (power-ups) ≤7.5 kW
(10 hp)
Switching on input supply (L1/N, L2/L, L3) (power-ups) 11–22 kW
(15–30 hp)
The drive can run at -25% input voltage with reduced performance. The maximum output power of the drive is 75% if input voltage is -25%, and
1
85% if input voltage is -15%. Full torque cannot be expected at mains voltage lower than 10% below the lowest rated supply voltage of the drive.
9.3 Motor Output and Motor Data
9.3.1 Motor Output (U, V, W)
Output voltage
Output frequency
+
Output frequency in VVC mode
Switching on output
Ramp time
9.3.2 Torque Characteristics
Starting torque (constant torque)
Overload torque (constant torque)
Starting current
120 | Danfoss A/S © 2022.02
PK37 0.37 PK55 0.55 PK75 0.75
(0.5) (0.75)
37.7 46.2
2.3 (5.1) 2.3 (5.1) 2.3 (5.1)
4.0 (8.8) 4.0 (8.8) 4.0 (8.8)
94.4 95.1
P1K1 1.1 P1K5 1.5
(1.0) (1.5) (2.0)
4 (12)
56.2 76.8 97.5
2.3 (5.1) 2.3 (5.1)
4.0 (8.8) 4.0 (8.8)
95.1 95.3 95.0
380–480 V: -15% (-25%)
200–240 V: -15% (-25%)
3.0% of rated supply voltage
≥0.9 nominal at rated load
Maximum 2 times/minute
Maximum 1 time/minute
0–100% of supply voltage
Maximum 160% for 60 s
Maximum 160% for 60 s
Maximum 200% for 1 s
AQ381425076031en-000101 / 130R1223
Specifications
P2K2 2.2
(3.0)
121.6
2.5 (5.5)
5.5 (12.1)
95.4
(L1/N, L2/L, L3)
to +10%
(1)
to +10%
(1)
50/60 Hz ±5%
Near unity (>0.98)
0–500 Hz
0–200 Hz
Unlimited
0.01–3600 s
(1)
(1)
