Table 14: Legend to Section B
Number Key Function
6 Status Shows operational information.
7 Quick Menu Allows access to programming parameters for initial set-up instructions and many detailed application
instructions.
8 Main Menu Allows access to all programming parameters.
9 Alarm Log Shows a list of current warnings, the last 10 alarms, and the maintenance log.
C. Navigation keys and indicator lights (LEDs)
Navigation keys are used for programming functions and moving the display cursor. The navigation keys also provide speed control
in local operation. There are also 3 drive status indicator lights in this area.
Table 15: Legend to Section C, Navigation Keys
Number Key
10 Back
11 Cancel
12 Info
13 Navigation keys
14 OK
Table 16: Legend to Section C, Indicator Lights (LEDs)
Number Indicator Light
15 On Green
16 Warn Yellow
17 Alarm Red
D. Operation keys and reset
Operation keys are at the bottom of the LCP.
Table 17: Legend to Section D
Number Key Function
Starts the drive in hand-on mode.
18 Hand On
•
19 Off Stops the motor but does not remove power to the drive.
Puts the system in remote operational mode.
20 Auto On
44 | Danfoss A/S © 2022.02
Function
Reverts to the previous step or list in the menu structure.
Cancels the last change or command as long as the display mode has not changed.
Press for a definition of the function being shown.
To move between items in the menu, use the 4 navigation keys.
Press to access parameter groups or to enable a selection.
Function
ON turns on when the drive receives power from the mains voltage, a DC bus terminal or a 24 V
DC external supply.
When warning conditions are met, the yellow WARN LED turns on, and text appears in the dis-
play area identifying the problem.
A fault condition causes the red alarm LED to flash, and an alarm text is shown.
An external stop signal by control input or serial communication overrides the local hand on.
