VLT® Midi Drive FC 280
Operating Guide
7 Application Examples
7.1 Introduction
The examples in this section are intended as a quick reference for common applications.
•
Parameter settings are the regional default values unless otherwise indicated (selected in parameter 0-03 Regional Settings).
•
Parameters associated with the terminals and their settings are shown next to the drawings.
•
Required switch settings for analog terminals 53 or 54 are also shown.
7.2 Application Examples
7.2.1 AMA
Table 50: AMA with T27 Connected
FC
+24 V
12
+24 V
13
D IN
18
D IN
27
D IN
32
33
D IN
+10 V
50
A IN
53
COM
55
102 | Danfoss A/S © 2022.02
Parameters
Function
Parameter 1-29 Automatic Motor Adaptation (AMA)
Parameter 5-12 Terminal 27 Digital Input
*=Default value
Notes/comments:
Set parameter group 1-2* Motor Data according to motor specifications.
If terminals 13 and 27 are not connected, set parameter 5-12 Terminal 27 Digital Input to [0]
No operation.
Setting
[1] Enable complete AMA
*[2] Coast inverse
N O T I C E
AQ381425076031en-000101 / 130R1223
Application Examples
