VLT® Midi Drive FC 280
Operating Guide
6.9 Commissioning and Validation
6.9.1 Safety Guidelines
Always perform a commissioning test after installation, maintenance, retrofit, and reconfiguration.
When commissioning/recommissioning:
• Secure the site in accordance with regulations (barrier, warnings, signs, and so on).
• Only qualified personnel are allowed to commission/recommission the system.
• Refer to the guidelines, information, and specifications stated in the Operating Instructions of relevant programmable control
system.
• Make sure that no personal injury and/or material damage can occur, even if the plant/machine moves unintentionally.
ELECTROSTATIC DISCHARGE
Electrostatic discharge can damage components.
-
Ensure discharge before touching the safety option, for example, by touching a grounded, conductive surface or by wearing
a grounded armband.
RISK OF ELECTROCUTION
-
Never wire the electrical connections on the drive while voltage is applied.
-
Switch off power.
-
Make sure that the control cabinet is provided with access lock or warning signs.
-
DO NOT switch on the voltages until the system is commissioned.
Refer to other chapters of this Operating Guide for further information of the drive. Refer to VLT® Motion Control Tool MCT 10 Oper-
ating Guide for further information on the Safe Plug-in.
6.9.2 Commissioning Requirements
The procedure requires installation of MCT 10 setup software, version 5.30 or later, and a successful connection to VLT® Midi
Drive FC 280 with built-in safety option.
• Configure the safety option in the MCT 10 with safe plug-in. Ensure only to configure safety functions that are wired up to the
safety option inputs.
• Ensure that the device number (serial number and order number) of the safety option on the drive matches the device number
of the safety option in the MCT 10 safe plug-in.
• Ensure that the drive is ready for commissioning.
The following components are required to perform the necessary steps for commissioning the safety option.
• VLT® Motion Control Tool MCT 10 set-up software (licensed version).
• USB or fieldbus connection or RS485 interface adaptor for connecting the control card of the drive with the PC.
If RS485 is used, the protocol for serial communication needs to be set to [0] FC-MC in parameter 8-30 Protocol (only accessible
through the LCP). When setting up the option for the first time, ensure to have a commissioning report at hand, see further informa-
tion in VLT® Motion Control Tool MCT 10 Operating Guide.
Only LCP software version 7.0 or newer is supported.
Danfoss A/S © 2022.02
N O T I C E
C A U T I O N
W A R N I N G
N O T I C E
Safety Functions
AQ381425076031en-000101 / 130R1223 | 91
