VLT® Midi Drive FC 280
Operating Guide
6.3.2.3 SS1-t Timer Start
If one of the following events is detected, SS1-t timer starts immediately:
• Terminal 37 becomes low.
• Terminal 38 becomes low.
• SS1-t active command received on fieldbus.
6.3.2.4 SS1-t Timing Quit
When SS1-t timer starts and does not expire, the SS1-t timer can be paused and reset when all of the following conditions are met:
•
When parameter 42-24 Restart Behavior is set to [1] Automatic, terminal 37 and terminal 38 are both high.
•
SS1-t inactive command received on fieldbus.
6.3.2.5 Safe State of SS1-t
The safe state of SS1-t is STO triggered before timer expires. If any internal fault is detected or external fault happens, the drive
triggers STO at any time.
Assess the risk of STO interrupting SS1-t.
6.3.2.6 Timing Precision
The timing precision is:
Lower limit = N × (1 − 0 . 1%)
Upper limit = (N + 0.05) × (1 + 0 . 1%)
N is the set time (set in parameter 42-42 Delay Time), and the unit is seconds.
6.4 Safety Digital Input
6.4.1 Valid Voltage
• The valid voltage range of terminal 39 should be 0 V, PELV.
• The valid voltage range of terminal 37 and 38 should be 0–24 V, PELV, refer to terminal 39.
• If the voltage on terminal 37 or 38 is over 30 V, the drive enters protection mode and triggers STO.
• If the voltage on terminal 37 or 38 is over 60 V, the circuitry of the drive will be damaged.
6.4.2 Debouncing
Some devices, for example safety PLC, generates a test pattern on its output for stuck checking. These test patterns can interrupt
the drive. The drive can ignore these test patterns on terminal 37 and 38 if they stay at low level (≤1.8 V) for no longer than 5 ms.
To activate STO (or SS1-t) effectively and stably, keep the 2 channels both at low level for at least 1 s.
62 | Danfoss A/S © 2022.02
N O T I C E
N O T I C E
Safety Functions
AQ381425076031en-000101 / 130R1223
