Scanning Documents - Fujitsu IMAGE SCANNER FI-4860C Operator's Manual

1.9 Scanning Documents

The following shows the procedure for scanning documents using the "ScandAll 21" application
(simply called "ScandAll 21" from here on.)
1. Load the documents on the hopper.
For details on how to load documents, refer to the section "1.6 Loading Documents on
the Hopper."
2. Adjust the stacker table to the document size.
ATTENTION
3. Start up ScandAll 21
From [Start] menu, select [Program] - [Scanner Utility for Microsoft Windows] - [ScandAll
21]. This starts up ScandAll 21.
4. Select the scanner to use
Select [Select Source] from the [Scan] menu.
22

1.9 Scanning Documents

- When long documents are loaded on the
hopper, extend the stacker extension.
- When short documents are loaded, adjust the
stopper length.
