Fujitsu IMAGE SCANNER FI-4860C Operator's Manual page 70

Duplex color scanner
Hide thumbs Also See for IMAGE SCANNER FI-4860C:
Table of Contents

Advertisement

3. Slide the Pick roller unit leftward a little and disengage the right ring form the shaft.
Pick roller unit
3
Ring(hidden)
Shaft(hidden)
4. Wipe the Pick rollers (2 positions) and the Separation roller using a cloth
moistened with cleaner F1.
Ring
Pick roller unit
45
3.3 Cleaning the Rollers
