Fujitsu IMAGE SCANNER FI-4860C Operator's Manual page 154

Symptom11
Do the documents satisfy the
conditions described in "Precautions"
in "6.2 Document Quality"?
YES
Is the length of the documents shorter
than 80mm and is the paper length
set [Normal]?
NO
Is there any foreign objects in the
ADF paper path?
NO
Is the Pad ASSY installed properly?
YES
Document jam occurs frequently.
NO
Use documents which satisfy
the requirements.
YES
Select paper length [Short] in
Paper Length setup mode.
YES
Clean the ADF paper path or
remove the foreign objects.
(* 2)
NO
Re-install the Pad ASSY
properly. (* 3)
Continued on next page
5.2 Troubleshooting
5
131
