LCD Descriptions
display
Baud Rate Specifies the control
data transfer rate for
TPS interface.
Imprinter When both fi-
486PRFR(Front
side/Pre-print) and
fi-486PRRE(Rear
side/Post-print) are
installed, specifies
which one to setup.
Numbering When either fi-
486PRFR(Front
side/Pre-print) or
fi-486PRRE(Rear
side/Post-print) is
installed, set the
numbering parame-
ters.
Ink Shows the remain-
ing ink amount.
Reset remaining
amount ink counter
when the Print car-
tridge is replaced.
Selectable Default
parameters
19200/ 9600
9600/
4800/
2400
Pre/Post
Numbering Numbering
: On/Off : Off
Digits Digits
: 5/8 : 5
Initial No.: Initial No.:
5digit: 0-99999 00000
8digit:0-
16777215
Reset at
Reset at hop- hopper
per empty: On/ empty: On
Off
-
Mode Remarks
On- Off-
line line
Not Avail- New setting
Avail- able valid after
able turning on
the power
again.
- Avail- Avail-
able able
Avail- Avail- Setup done
able able via the PC
has the prior-
ity.
- Avail- Avail-
able able
7.2 Setup mode functions
