6.4 Print Prohibited Area

If there are prints in the area A, document size may be mis-detected. Prints in the area B of a
document may cause double-feed errors. Following figure shows print prohibited area on a
document. If double-feed detection is to be enabled, it is recommended to avoid printing in these
areas in the original documents and the forms design.
For the details of double-feed detection, please refer to "Appendix-2 Double Feed Detection
Conditions."
Reading
reference
position
Center of document
113 (4.45") 134 (5.28")
79 (3.12") 96 (3.78")
Front side
Reading surface
10 10
34 (1.34")
(0.39") (0.39")
(Unit : mm)
Top of document
: Area A
: Area B
Bottom of document
10 10
(0.39") (0.39")

6.4 Print Prohibited Area
