Fujitsu IMAGE SCANNER FI-4860C Operator's Manual page 153

Are the Pick roller unit and the
Brake roller unit installed properly?
Have you scanned many sheets
beyond the life of the rollers since the
last replacements?
(300k sheets)
Contact an authorized FUJITSU
Scanner service provider.
(* 1) For the details on required conditions, refer to the section "6.2 Document Quality."
(* 2) For the details on the double-feed detecting conditions, refer to "Appendix 2 Double-feed
Detection Conditions."
(* 3) For the details on how to clean Pad ASSY, refer to "Chapter 3, DAILY CARE."
(* 4) For the details on how to replace Pas ASSY, refer to "Chapter3, DAILY CARE."
(* 5) For the details on scanner cleaning, refer to "Chapter 3 DAILY CARE."
(* 6) For the details on how to replace and install Pick roller unit and Brake roller unit, refer to
"Chapter 4 REPLACING CONSUMABLES."
130
5.2 Troubleshooting
Continued from the previous page
NO
YES
YES
NO
nstall the Pick roller and the
Brake roller properly. (* 6)
Replace the Pick roller unit and
the Brake roller unit as
necessary. (*6)
