23. Setting Baud rate of TPS interface
1) Press (Next button) or
2) At <Screen23>, press
Baud rate.
HINT
Baud rates available are as follows:
(1) 19200 bps
(2) 9600 bps
(3) 4800 bps
(4) 2400 bps
By pressing (Left arrow button), selection moves from (4) to (1).
By pressing (Right arrow button), selection moves from (1) to (4).
HINT
(3) Press (Enter button) and make the setting valid.
Press (EXIT button) at the end and the LCD display goes back to [Ready]
screen.
(Previous button) and let LCD display <Screen23>.
<Screen23>
3
! 2 B a
= 1 9 2 0 0
(Left arrow button) or
The blinking item is the one selected.
It is recommended to set the Baud rate at 9600
bps.
t
u d R a e
/ 9 6 0 0 / 4
(right arrow button) and select
7.3 Setup Mode Details
8 0 0
7
