6.5 Grounding Color Areas

The shaded area in the Figure below, top 3mm on both sides of a document, should have paper
grounding color (white).
The area can be dropout color. If this cannot be followed, turn the white level follower off when
reading.
For the details on dropout color, please refer to "Appendix-1 Dropout Color."
Reading
reference
150

6.5 Grounding Color Areas

Grounding color
(white) or drop-out
color area
Main scanning direction
3 mm (0.12")
