Continued from the previous page
Is the Pad ASSY dirty?
NO
Is the Pad ASSY worn out?
NO
Is the Pad ASSY installed properly?
YES
Are the Pick roller, the Brake roller
or the document path dirty?
NO
YES
Clean the Pad ASSY. (* 3)
YES
Replace the Pad ASSY. (* 4)
NO
Install the Pad ASSY properly.
(* 4)
YES
Clean the dirty parts. (* 5)
Continued on next page
5.2 Troubleshooting
5
129
