Fujitsu IMAGE SCANNER FI-4860C Operator's Manual page 125

6. Attach the Lamp socket cover in the reverse order of its removal. Make sure that
the metal part is fixed firmly.
7. Close the glass sheet guide. Make sure that the guide is fixed firmly.
8. Lift the Upper transport unit a little to release the safety lock and then lower the
transport unit slowly.
9. Clear the Front-side lamp counter.
Please refer to the section "7.3 Setup Mode Details", "9. Abrasion counter reset."
HINT
102
4.6 Replacing the Front-side Lamp
You can check the cumulative lamp-on hours
from the operator panel Test mode.
For the details, refer to the section "7.5 Test
Mode Details," "3.Display the cumulative lamp-
on hours."
