■ Document separation force adjustment

If the following error occurs frequently, adjust the brake force of the Brake roller using setup
mode.
- Double-feed
- Mis-pick
- Paper jam1
1. Enter into the setup mode.
Please refer to the section "1.3 Basic Operations of Operator Panel", "Using the setup
and Test mode."
The following screen appears.
Choose an appropriate setting based on the thickness of the document you are
scanning and the error.
By pressing
By pressing
(1)
(2)
(3)
(4)
(5)
When the desired option appears, press
112
5.1 Clearing Document Jams
! 0 1
= T
(Right arrow button), the LCD display changes items from (5) to (1).
(Left arrow button), the LCD display changes items from (1) to (5).
- Document thickness: Thick
- Document thickness: Medium thick
- Document thickness: Mid
- Document thickness: Medium thin
- Document thickness: Thin
S e p a r a
h i n
(Enter button) to select it.
t i o n
T h i c k
