3. Pressing down the upper part of the Guide plate with your fingers at two positions
and pull the plate toward you to remove it.
Pad ASSY
Guide plate
4. Turn the bail of the Brake roller upward and release the lock.
Brake roller
Bail
48
3.3 Cleaning the Rollers
