1.8 Inserting Documents Manually
When the scanner is in Manual Mode, set the documents as follows.
1. Lift the Pick roller until it is held by the magnet catch. The hopper table moves up
to feed position.
2. Place documents face-up at the center of the hopper table.
HINT
20
1.8 Inserting Documents Manually
Be careful not to get your finger or things
caught in the mechanism when the hop-
CAUTION
per table moves up.
For information on setting Manual feed time-
out, refer to "Chapter 7 OPERATOR PANEL
MENUS."
