c. Zone group 9 can be identified by the
d. Issue the following command to access all hosts smp_discover_list:
e. Zone group 9, 10, 11, 12, 13, and 14 can be identified by the
5.3.7 Disabling Zoning using Windows
PENDING - Remove references to sg and replace with SCSI device handles.
Step 1 : From the host server, identify the SCSI devices that are associated with the Ultrastar Data60
IOMs.
a. Issue the following command:
b. Identify the SCSI devices from the output. The device information follows SCSI0. The
Step 2 : Locate the IP Address for each IOM using sg_ses page 7.
a. Issue the following command:
b. The IP Address for each IOM will appear at the end of each resulting line. Each IP
Step 3 : Verify the IOM SAS Address that matches each SCSI device that is linked to each IOM using
sg_vpd page 83h.
The above example displays PHYs 0-13 as being in zone group 9. All other devices are
labeled as
inaccessible
to. The step can be repeated on other hosts to see what zone group each host has
access to.
smp_discover_list --ignore /dev/bsg/expander-9:39
group in each of their respective zones. The above example displays PHYs 0-13 as being
in zone group 9, PHYs 14-27 as being in zone group 10, and so on.
Note: The operating system associates each SEP device as a SCSI device. The
SCSI device of the SEP can be used to get status from or control elements
within the enclosure.
sg_scan -s | findstr /i H4060-J
devices appear as SCSI0:1,62,0 and SCSI0:1,124,0 bolded in the example below.
SCSI0:1,62,0 claimed=0 pdt=dh
0101
0428
SCSI0:1,124,0 claimed=0 pdt=dh
0101
0428
sg_ses <dev> -p7 | finstr /i esce
Note: For scsi<dev>, type the number of the SCSI device recorded in
the previous step.
Address is labeled for either IOM A or IOM B and occurs after the last comma as seen
bolded in the following example.
located at the end of each line in zone 9.
ZG:9
because the host is displaying the only devices it has access
