4. Part Replacement
User Guide
4.9 Chassis Replacement
Figure 150: Remove Inner Rail
b. Locate and unlatch the springlock on the side of the inner rail.
Figure 151: Inner Rail Spring Latch
c. Slide the inner rail toward the front of the enclosure to unlock it from the pegs that secure
it to the sidewall and pull it free.
Note: Follow the next step if the cable tray was installed.
Step 24 : Uninstall the Cable Tray by removing the M3 x 8mm screws using the long T10 Torx head
screwdriver.
