NOTE: If the terminal is idle for several minutes the Local Management Password
screen redisplays and the session ends. This idle time can be changed in the General
Configuration screen in
Menu Descriptions
Table 3-1 Main Menu Screen Menu Item Descriptions
Menu Item
CHASSIS
MODULES
3.4

MODULE SELECTION SCREEN

Screen Navigation Path
For 6C105 chassis:
Password > Main Menu > Module Selection
For 6C107 chassis:
Password > Module Selection
When to Use
To select a module in the chassis and the Module Menu screen, which is the access point to the set
of Local Management screens for the selected module. The Module Selection screen is the access
point to the Local Management screens for all modules installed in the 6C105 or 6C107 chassis.
Section 5.2.9.
Screen Function
Provides access to the Chassis Menu screen that is used to configure
the chassis, access current chassis power supply and environmental
status, and perform port and VLAN redirect functions.
To access and use the Chassis Menu screen, refer to
instructions.
Provides access to the Module Selection screen that is used to select
individual modules in the chassis for management purposes. If module
management is desired at this time, proceed to
Module Selection Screen
Section 4.1
Section
Accessing Local Management
for
3.4.
3-9
