Screen Example
Figure 6-5 Redirect Configuration Menu Screen
Field Descriptions
Refer to Table 6-4 for a functional description of each menu item.
Table 6-4 Redirect Configuration Menu Screen Field Menu Item Descriptions
Menu Item
PORT REDIRECT
CONFIGURATION
VLAN REDIRECT
CONFIGURATION
Screen Function
Used to redirect traffic from a source switch port to a destination
switch port. For details, refer to
Used to configure the switch module to direct traffic from a VLAN to a
particular switch port. For details, refer to
Redirect Configuration Menu Screen
Section 6.6.
Section
Port Configuration Menu Screens
6.7.
6-15
