Field Descriptions
Refer to Table 8-5 for a functional description of each screen field.
Table 8-5 Current VLAN Egress Configuration Screen Field Descriptions
Use this field...
Port
(Read-Only)
Egress
(Read-Only)
8.7

VLAN PORT CONFIGURATION SCREEN

When to Use
To see and/or make changes to the port parameters affecting
•
the Port VLAN Identification (PVID) to reassign the port to a different PVID,
•
the acceptable frame type that the port will transmit or receive frames of VLANs other than the
static VLANs created on the switch,
•
the ingress filtering on the port, which can be enabled or disabled to filter out (drop) frames that
are not on the switch egress list, or
•
the GARP VLAN Registration Protocol (GVRP) status, which can be enabled or disabled.
To...
See a list of the ports associated with the VLAN ID shown in the line
above the Port and Egress lists.
See the current egress setting (UNTAGGED, TAGGED, or NO) for
each port.
VLAN Port Configuration Screen
802.1Q VLAN Configuration Menu Screens 8-17
