8.9

PROTOCOL PORT CONFIGURATION SCREEN

When to Use

To perform the following:
•
Display the ports.
•
Show which ports are set to the line item containing the VID/Classification (Classification Rule)
of interest in the VLAN Classification Configuration screen described in
•
Add or remove ports from being associated with the Classification Rule.
•
Add ports to the VLAN Forwarding List of the switch module.
NOTE: The ports can only be added to the VLAN Forwarding List of an existing VLAN.
If the VLAN does not exist, it must be created before the ports can be assigned to the
VLAN Forwarding List. VLANs are created using the Static VLAN Configuration screen
described in

How to Access

Use the arrow keys to highlight the line item of interest on the VLAN Classification Configuration
screen and press ENTER. The Protocol Port Configuration screen,
Section 8.3.
Protocol Port Configuration Screen
802.1Q VLAN Configuration Menu Screens
Section 8.8.
Figure 8-9, displays.
8-35
