Protocol Port Configuration Screen
Table 9-9 Protocol Port Configuration Screen Field Descriptions (Continued)
Use this field...
Port
(Read-Only)
Classify
(Toggle)
SET ALL PORTS
(Toggle)
9.7.1

Assigning Ports to a PID/Classification

To assign one or more ports, or all ports simultaneously, to a PID/Classification (Classification
Rule), proceed as follows:
Assigning One or More Ports Individually
1. Use the arrow keys to highlight the Classify field adjacent to the Port number.
2. Press the SPACE bar to toggle the Classify field to either NO or YES. YES associates the port
to the priority shown in the Classification Rule field.
3. If more than one port is being set, repeat the first two steps for each port.
4. Use the arrow keys to highlight the SAVE command at the bottom of the screen.
5. Press ENTER. The message "SAVED OK" displays and the settings are saved.
9-34 802.1p Configuration Menu Screens
To...
See the number of each port.
See which ports are set to the PID/Classification indicated in the
Classification Rule field (see
between YES and NO, which determines whether or not the associated
port is set to the Classification Rule.
NOTE: As each Classify field is highlighted, the Event
Message Line (not shown) at the top of the screen indicates
the port type. For example: Fast Ethernet Front Panel, FTM
Backplane Port 3, and Gigabit Ethernet VHSIM.
If a port cannot be configured, "NO" displays without
brackets.
For details about assigning ports, refer to
Toggle between YES and NO. This determines whether or not all ports
will be assigned to the classification rule shown in the Classification
Rule field. NO is the default. For details about setting all ports
simultaneously, refer to
Figure 9-8). The Classify field toggles
Section
Section 9.7.1.
9.7.1.
