Field Descriptions
Refer to Table 8-4 for a functional description of each screen field.
NOTE: These fields are read-only fields, however, highlighting a line using the arrow
keys and pressing ENTER causes the Current VLAN Egress Configuration screen to
display. That screen shows the egress setting for each port associated with the VLAN ID
in the highlighted line.
Table 8-4 Current VLAN Configuration Screen Field Descriptions
Use this field...
VLAN ID
(Read-Only)
FDB ID
(Read-Only)
VLAN Type
(Read-Only)
Ports On Egress
(Read-Only)
To...
See a list of the VLANs currently recognized by the switch.
See the Filter Database ID (FDB ID) of the associated VLAN.
See the VLAN Type of the associated VLAN (Static or Dynamic). An
example of a dynamic VLAN is a GVRP VLAN.
See if the ports associated with each VLAN are on the egress list.
Current VLAN Configuration Screen
802.1Q VLAN Configuration Menu Screens 8-15
