Module Statistics Menu Screen

11.1 MODULE STATISTICS MENU SCREEN
When to Use
To obtain the following information:
•
Statistics concerning frame traffic through each switch port.
•
MIB II statistics for each switched interface.
•
Statistics gathered by the embedded RMON agent on the switch.
•
Statistics on any optional Fast Ethernet or Gigabit Ethernet HSIM or VHSIM installed in the
module.
NOTE: An HSIM or VHSIM Statistics menu item does not display for non-Ethernet
HSIMs or VHSIMs. If a non-Ethernet HSIM or VHSIM is installed, refer to its user's guide
for more information.
How to Access
Use the arrow keys to highlight the MODULE STATISTICS menu item on the Module Menu
screen and press ENTER. The Module Statistics Menu screen,
11-2 Module Statistics Menu Screens
Figure 11-1, displays.
