Switch Statistics Screen

Table 11-1 Module Statistics Menu Screen Menu Item Descriptions (Continued)
Menu Item
HSIM/VHSIM
STATISTICS
CHASSIS
ENVIRONMENTAL
STATISTICS
11.2 SWITCH STATISTICS SCREEN
When to Use
To obtain switch statistics about the number of frames received, transmitted, filtered, and
forwarded by each switch port.
How to Access
Use the arrow keys to highlight the SWITCH STATISTICS menu item on the Module Statistics
Menu screen and press ENTER. The Switch Statistics screen,
11-4 Module Statistics Menu Screens
Screen Function
Displays the statistics screen when an optional Fast Ethernet or Gigabit
Ethernet HSIM or VHSIM is installed in the switch module. An HSIM
or VHSIM Statistics menu item does not display for non-Ethernet
HSIMs or VHSIMs. If a non-Ethernet HSIM or VHSIM is installed,
refer to its user's guide for more information.
Displays the statistics screen for fan and power supplies. For details,
refer to Section 11.5.
Figure 11-2, displays.
