Screen Example
Figure 7-3 Spanning Tree Configuration Screen
Field Descriptions
Refer to
Table 7-3
for a functional description of each screen field.
Table 7-3 Spanning Tree Configuration Screen Field Descriptions
Use this field...
VLAN
– top of screen
(Read-Only)
To...
See a list of the VLAN or Spanning Tree Instances. This field also
enables you to add or delete other VLAN Instances.
Spanning Tree Configuration Screen
802.1 Configuration Menu Screens
7-7
